Single Phase Distribution Transformer
- Upto 25KVA
- Primary – Upto 33kv
- Core – CRGO / Amorphous
- Windings – Al / Cu
- CSP / Non CSP
- Type tested at CPRI / ERDA
- Approved by BIS for ratings upto 25KVA EEL-2
Product Description :
Three Phase Distribution Transformer
- 10kva to 2500kva
- Primary – Upto 33kv
- Core – CRGO / Amorphous
- Windings – Al / Cu
- Sealed / Non Sealed
- OLTC / OCTC
- Mineral Oil / K-Class Oil
- Completely Self Protected
- Comply with BEE 5-Star and BIS EEL3
- Type tested at CPRI / ERDA
- Approved by BIS and BEE for ratings upto 2500KVA
Product Description :
Distribution Transformer Manufacturers
CSP means Completely Self Protected Feature which contains the fittings like LT Circuit Breaker, Lighting Arrestors and HV Fuse Links. The purpose of CSP feature is that it protects the transformer from any differential load, lighting affects and also protects the transmission system from any short circuit inside the transformer.
We offer different grades of CRGO like M4, M3, MOH, ZDKH and ZDMH based on efficiency requirements of the Transformer. We also use different types of CRGO construction such as
Distribution Transformer Manufacturers
- CRGO - Wound core (Both Shell type and Core type)
- CRGO - Stacked core
With the use of Amorphous core we can offer the least no load losses possible for any given rating. The Transformer with amorphous core has low eddy current losses, low Hysteresis losses, low skin affect resulting in just 20% of the losses of a conventional CRGO core transformer.
Bureau Of Energy Efficiency
Our Energy Efficient transformers are certified by BEE and assigned 3-Star and 5-Star rating based on the losses. This Certification is based on the Total losses at 50% and 100% of full load. The star rating from 1-star to 5-star Distribution Transformers enables us to provide minimum losses resulting in maximum efficiency of the transformer.
| BEE | 1-Star | 2-Star | 3-Star | 4-Star | 5-Star | BIS | Level-1 | Level-2 | Level-3 | Level-4 | Level-5 |
|---|---|---|---|---|---|---|---|---|---|---|
| RATING (kVA) | Max losses at 50% (watts) | Max losses at 100% (watts) | Max losses at 50% (watts) | Max losses at 100% (watts) | Max losses at 50% (watts) | Max losses at 100% (watts) | Max losses at 50% (watts) | Max losses at 100% (watts) | Max losses at 50% (watts) | Max losses at 100% (watts) |
| 16 | 135 | 440 | 120 | 400 | 108 | 364 | 97 | 331 | 87 | 301 |
| 25 | 190 | 635 | 175 | 595 | 158 | 541 | 142 | 493 | 128 | 448 |
| 63 | 340 | 1140 | 300 | 1050 | 270 | 956 | 243 | 870 | 219 | 791 |
| 100 | 475 | 1650 | 435 | 1500 | 392 | 1365 | 352 | 1242 | 317 | 1130 |
| 160 | 670 | 1950 | 570 | 1700 | 513 | 1547 | 462 | 1408 | 416 | 1281 |
| 200 | 780 | 2300 | 670 | 2100 | 603 | 1911 | 543 | 1739 | 488 | 1582 |
Standard Fittings
- HV and LV Bushings
- HV and LV Metal Parts
- Bi-metallic Connectors
- Oil Level Gauge
- Thermometer pocket
- Cooling Tubes/Radiators/Corrugation Panels
- Pressure Relief Valve
- Explosion Vent pipe
- Company Logo plate/label
- Hardware fittings
Optional Fittings
- Drain valve
- Filter valve
- Radiator valves
- Oil and Winding Temperature Indicators
- Oil Immersed Circuit Breaker/MCCB
- Off Circuit Tap Switch/On Load Tap Changers
- Cable Box for LV and HV terminals
- Silicagel Breather
- Lightning Arrestors /Arcing Horns
- HV Fuse Links
- Conservator
- Bi-directional Rollers
Technical Specification
| Applicable Standards | IS, IEC, ANSI, BS |
| Cooling | ONAN |
| Insulating Oil | Mineral Oil |
| Winding Material | Copper/Aluminium |
| Winding Insulation | DPC/TPC/Super Enamel Covering |
| Frequency | 50Hz, 60Hz |
| Vector Group | As specified |
| Impedance | As specified |
